4-Strand High-Tensile Polyester Fishery Ropes with Durable, Lightweight, and Saltwater Resistant
Description:
GBT 18674-2018 4-strand Polyester Fishery Ropes is a relatively new synthetic fiber rope constructed be Z-twist(right hand lay),their strands S-twist and their roping yarns Z-twist.It has high density about 1.38g/cm3.Nets which made by 4-strand Polyester Fishery Ropes has a faster settlement in the water, suitable for making fishing gear requiring a faster settlement speed, such as purse Seine.It has high strength which not be changed when the ropes are wet.It is good elasticity, small elongation, smooth fiber surface, small water resistance, fast dehydration, good heat and light resistance, sunlight has little influence on its strength, Strong acid resistance.
Product Features:
High Tensile Strength,Designed for demanding fishery applications, these ropes can handle heavy loads and withstand extreme pulling forces without breaking
Durable Construction,Made from premium-grade polyester, the ropes exhibit excellent abrasion resistance, ensuring long-term use in tough marine environments
Saltwater Resistant,Exceptional resistance to saltwater corrosion and marine elements, making them ideal for prolonged exposure to sea conditions
Lightweight and Flexible,Despite their strength, the ropes remain lightweight and highly flexible, ensuring ease of handling during fishing operations
UV Resistance,Polyester material provides superior resistance to UV rays, reducing degradation and extending the product's lifespan
Low Stretch,Minimal elongation under load ensures stable and reliable performance, even during heavy-duty applications
Easy Handling,Soft texture and smooth surface make it easy to splice, knot, and deploy, improving operational efficiency
Wide Range of Applications,Suitable for commercial fishing, mooring, towing, and other marine operations requiring high performance and reliability
Main Technical Specifications:
1.Standard: GB/T 18674-2018
2.Material: Polyester
3.Diameter: 10mm to 72mm
4.Construction: 4-strand hawser-laid
5.Type: Knit
6.Test: Destructive and Tension test
7.Classification Certificates: RINA ,BV ,CCS ,CR ,NK ,ABS ,DNV ,LR and Mill Certificate
8.Color: White, or as your needs
9.Application: Purse Seine,Fishing rope,Fishing net, Towing gear, positioning gear and mooring vessels
10.Advantages: high density, good elasticity, small elongation, smooth fiber surface, small water resistance, fast dehydration, good heat and light resistance, Strong acid resistance
Main Technical Parameters:
Linear density and minimum breaking force GBT 18674-2018 4-strand Polyester Fishery Ropes
Reference NO.
mm |
Linear density |
Minimum breaking strength kN |
Nominal
ktex |
Tolerance
% |
Superior Product |
Top Qualified Product |
Qualified Product |
| 10 |
61.7 |
±8 |
19.0 |
17.5 |
15.6 |
| 12 |
88.8 |
28.0 |
26.0 |
23.0 |
| 14 |
121 |
35.5 |
32.8 |
29.0 |
| 16 |
158 |
±5 |
47.5 |
44.0 |
39.0 |
| 18 |
200 |
56.0 |
51.5 |
46.0 |
| 20 |
247 |
71.0 |
65.5 |
58.5 |
| 22 |
299 |
85.0 |
78.5 |
70.0 |
| 24 |
355 |
100 |
92.5 |
82.5 |
| 26 |
417 |
118 |
109 |
97.5 |
| 28 |
484 |
132 |
122 |
109 |
| 30 |
555 |
150 |
138 |
124 |
| 32 |
632 |
170 |
157 |
140 |
| 36 |
800 |
212 |
195 |
175 |
| 40 |
987 |
265 |
245 |
218 |
| 44 |
1190 |
315 |
290 |
260 |
| 48 |
1420 |
375 |
345 |
310 |
| 52 |
1670 |
425 |
392 |
350 |
| 56 |
1930 |
500 |
462 |
412 |
| 60 |
2220 |
560 |
518 |
462 |
| 64 |
2530 |
630 |
583 |
520 |
| 72 |
3200 |
800 |
740 |
660 |
|
1.The reference number corresponds to the approximate diameter, in millimetres.
2.The linear density, in kilotex, corresponds to the net mass per length of the rope, expressed in grams per metre or in kilograms per kilometre.
3. The breaking forces relate to new, dry ropes.
4.When the rope fracture position including splice eye,the minimum breaking strength should be reduced 10%.
5. A force determined by the test methods specified in GB/T 8834 is not necessarily an accurate indication of the force at which that rope might break in other circumstances and situations. The type and quality of terminations, the rate of force application, prior conditioning and previous force applications to the rope can significantly influence the breaking force. A rope bent around a post, capstan, pulley or sheave may break at a significantly lower force. A knot or other distortion in a rope may significantly reduce the breaking force.
|
Drawing of GBT 18674-2018 4-strand Polyester Fishery Ropes:
Product Photo of GBT 18674-2018 4-strand Polyester Fishery Ropes:
FAQ:
Q0: Are you a factory or trading company?
A0: We are a professional manufacturer for synthetic rope, rope net, rope ladders and relevant etc. We also trade steel wire rope and etc.
Q1: What is your terms of packing?
A1: We use synthetic bags for package. We can pack the goods in your brand after your approval.
Q2: What is your terms of payment?
A2: T/T & LC.
Q3: What is your terms of delivery?
A3: EXW, FOB, CFR, CIF, DDU.
Q4: How about your delivery time?
A4: Generally, it will take 1 to 7 days after receiving payment. The specific delivery time depends on the products and the quantity.
Q5: Can you produce according to the samples?
A5: Yes, we can produce as your samples or drawings.
Q6: What is your sample policy?
A6: We can supply the sample it is stock available, while courier cost and sample cost (it depends) are to be covered by buyer. It will be refunded for next time order.
Q7: Do you test all your goods before delivery?
A7: We test our finished products & raw material by bathes, and as requirement by third party case by case
