GB/T8050-2017 4 Strand Polypropylene Monofilament Fibre Ropes
Description:
GB/T8050-2017 4 strand polypropylene monofilament fiber rope is made entirely of polypropylene. It can withstand extreme temperatures, severe weather, UV rays, chemicals, oil, abrasion and tearing. The twisted rope has good shock absorption, does not kink, has high tensile strength, durable knots and excellent performance, making it reliable for both indoor and outdoor use, as well as for unique home improvement projects, and for use on many commercial and construction sites. It also can be used as mooring ropes, towing rope and marine ship use.
Main Technical Specifications:
- Standard: GB/T8050-2017
- Material: Polypropylene monofilament
- Diameter: 20mm to 160mm
- Construction: 4-strand
- Structure: Z-twist(right hand lay)
- Test: Destructive and Tension test
- Classification Certificates: RINA ,BV ,CCS ,KR ,NK ,ABS ,DNV ,LR and Mill Certificate
- Color: White, Blue, Yellow, Orange as ordered
- Application: Indoor and outdoor use, unique home renovation, commercial and construction sites, marine use
- Advantages: Lightweight, durable & economical, good resistance to abrasion and UV light, Good environmental resistance
Main Technical Parameters:
| Reference NO.1 |
Linear density2.3 |
Minimum breaking strength kN4.5 |
|
Nominal
ktex
|
Tolerance
%
|
Unspliced ropes |
Ropes with eye-spliced terminations |
| 20 |
181 |
±5 |
53 |
47.7 |
| 22 |
219 |
60 |
54 |
| 24 |
260 |
71 |
63.9 |
| 26 |
306 |
80 |
72 |
| 28 |
354 |
95 |
85.5 |
| 30 |
407 |
106 |
95.4 |
| 32 |
463 |
125 |
113 |
| 36 |
586 |
150 |
135 |
| 40 |
723 |
180 |
162 |
| 44 |
875 |
224 |
202 |
| 48 |
1040 |
250 |
225 |
| 52 |
1220 |
300 |
270 |
| 56 |
1420 |
335 |
302 |
| 60 |
1630 |
400 |
360 |
| 64 |
1850 |
450 |
405 |
| 72 |
2340 |
560 |
504 |
| 80 |
2890 |
670 |
603 |
| 88 |
3500 |
800 |
720 |
| 96 |
4170 |
950 |
855 |
| 104 |
4890 |
1120 |
1008 |
| 112 |
5670 |
1250 |
1125 |
| 120 |
6510 |
1400 |
1260 |
| 128 |
7410 |
1600 |
1440 |
| 136 |
8360 |
1800 |
1620 |
| 144 |
9370 |
2000 |
1800 |
| 160 |
11600 |
2500 |
2250 |
|
1.The reference number corresponds to the approximate diameter, in millimetres.
2. The linear density, in kilotex, corresponds to the net mass per length of the rope, expressed in grams per metre or in kilograms per kilometre.
3. The linear density is obtained under reference tension and is measured as specified in ISO2307.
4. The breaking forces relate to new, dry and wet ropes.
5. A force determined by the test methods specified in ISO2307 is not necessarily an accurate indication of the force at which that rope might break in other circumstances and situations. The type and quality of terminations, the rate of force application, prior conditioning and previous force applications to the rope can significantly influence the breaking force. A rope bent around a post, capstan, pulley or sheave may break at a significantly lower force. A knot or other distortion in a rope may significantly reduce the breaking force.
|
Drawing of GB/T8050-2017 4 strand polypropylene monofilament fiber ropes:
Product of GB/T8050-2017 4 strand polypropylene monofilament fiber ropes:
